Zone 3.5" Adventure Series Lift Kit

This lift kit is built around replacement upper control arms that dwarf factory components and are made from fully-welded 1/8" steel plate and CNC-machined ball joint and bushing mounts to provide significant gains in suspension travel. The arms utilize high quality ball joints that can handle heavy-duty use and work in conjunction with stock-style rubber mount bushings to provide a quiet ride. A fully integrated front differential drop and differential skid plate system relocates the differential for optimal driveline angles. The included strut spacers provide a full 3.5" of lift and install easily on the factory struts without requiring the use of a strut compressor. A block and U-bolt system nets 2" of lift and provides an athletic level vehicle stance.

• Fully welded, heavy duty upper control arms that dwarf the factory arms
• CNC-machined UCA bushing and ball joint cups
• OE rubber bushings and greasable factory style ball joints for quiet, reliable, and low maintenance operation
• Improved UCA range of motion compared to stock arms
• UCAs utilize replaceable ball joints and bushings
• Fully integrated front differential drop and skid plate for optimal driveline angles

Attributes:

• Brand Name: Zone Offroad
• GTIN: 00810156360497
• Accommodates Factory Wheels: See Notes
• Adjustable: No
• Back Spacing: 4.5"
• Finish: Powdercoat
• Front Lift Height: 3.5"
• Front Lift Method: Strut Spacers
• Installation Difficulty: 3 out of 5
• Installation Time: 4-5 hrs
• Lift Type: Lift Kit
• Material: Steel
• Max Tire Size: 285 / 70
• Rear Lift Height: 2"
• Rear Lift Method: Lift Block
• Required Tools: Cut-off Tool
• Requires Metal Cutting: No
• Requires Welding: No
• Wheel Size: 17 x 9

Extended Information:

• Country of Origin: US
• Emissions : 1
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 48.0000 x 40.0000 x 24.0000 inches
• Weight: 74.3500 lb
