3.5 Inch Lift Kit - FOX 3.0 Bypass Factory Race Series - Chevy Silverado And GMC Sierra 1500 (19-24)

Built for strength performance and increased travel these upper control arms are ready to bolt-in with most leveled/lifted trucks. They use 1.5" OD x .120-wall tubular construction with an indexed ball joint cup to correct the ball joint positioning allowing additional down travel and camber adjustment. At the frame mounting ends are durometer-specific rubber bushings for maintenance-free operation while at the other end a quality greaseable ball joints for smooth quiet operation and superior durability. Arms are finished in a durable black powder coat with a billet aluminum dust cap ready for installation right out of the box.

• Builds off factory suspension geometry for improved performance with easy install.
• Optional weld on steering stops to help tire clearance to fenders control arms etc. Dependent upon wheel offset selected.
• Factory Protection Plus included.
• Front FOX 3.0 Factory Race Series IBP coil overs for unmatched performance and capability with simple adjustment of settings.
• Rear FOX 3.0 Factory Race Series IBP shocks for improved ride quality performance and capability.
• BDS HD upper control arms for strength and increased suspension travel.
• High misalignment angle greaseable heavy duty ball joints.
• Rubber control arm bushings to promote long life and no maintenance of the joint.
• Anodized ball joint cap to seal the top of the control arm ball joint cup from dirt and debris.
• Rear lift block kit to produce a level to slightly tail height stance.
• 1/4" wheel spacer provided to be used with the spare tire if needed.

Attributes:

• Brand Name: BDS Suspension
• GTIN: 00840416420920
• Front Lift Height: 3_5
• Front Lift Method: Coil Over
• Installation Time: 3-4 Hrs
• Pvg Product Status: Active
• Rear Lift Height: 1_5
• Rear Lift Method: Block
• Shocks Included: Yes

Extended Information:

• Country of Origin: US
• Emissions : Emissions Compliance Exempt
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Weight: 0 lb
